MIL-PRF-49080 Power Supplies, Pp-2953\(\)/U And Pp-6224\(\)/UThis specification establishes the performance and verification requirements for each of the following Power Supplies: the PP-2953\(\)/U and the PP-6224\(\)/U . The power supply furnishes 0-25 amperes over a voltage range of 24 to 32VDC from nominal 115/230 VAC at 50, 60 or 400 Hz single phase. The power supply can also operate from a 24 VDC storage battery in the battery standby mode.

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MIL-PRF-49080D
TABLE IV. Group B inspection.
Requirement
Inspection
Inspection
Paragraph
Paragraph
Recovery time
Overload protection
Remote sensing
Bench handling
Electric Strength**
Retained Charge**
**Note: Testing not required if product is Listed by Underwriter Laboratories
4.4.3
Group C inspection. Group C inspection shall consist of the inspections identified
in TABLE V below. Samples shall be selected in accordance with 4.4.3.1.1.
TABLE V. Group C inspection.
Inspection
Requirement
Inspection
Sample
Paragraph
Paragraph
Numbers
Frequency - voltage - load matrix
1-4
Stability: Method 2
1-4
Temperature coefficient
1
2
Temperature test
Immersion
2
Vibration
3
Shock, ballistic
4
4.4.3.1
Group C sampling.
4.4.3.1.1  Sampling for inspection (Group C). Four samples shall be selected at random
from units having passed Group B inspections within12 months after First Article completion
and within 12 months of each prior Group C sampling,. The samples shall be numbered 1
through 4. These units shall have passed Group A and B inspections. Each sample shall be
subjected to each inspection specified for the specific sample number.
4.4.3.2
Group C failures. Actions relative to Group C failures shall be as specified in
the contract.
4.4.3.3
Reinspection of conforming Group C sample units. Unless otherwise specified,
sample units which have been subjected to and passed Group C inspection may be accepted on
the contract or order provided all damage is repaired and the sample units are re-subjected to
and pass Group A inspection and the frequency-voltage-load matrix inspection of 4.5.1.2 (see
Sub-group I, TABLE V). Printed wiring assemblies shall not be repaired (3.5).
4.5
Electrical tests.
4.5.1
Voltage tests, input and output. Whenever test requirements call out this paragraph,
both sub-paragraphs apply.
